| Input power | AC380V±15%, 3 Phase, 50-60Hz |
| Rated Input current | 18A |
| Rated Output current | 30-270A |
| Rated Output voltage | 27.5V |
| Duty cycle | 60% |
| Efficiency | 85% |
| Power factor | 0.73 |
| Insulation class | F |
| Protection class | IP21 |
| Dimension | 400*159*300mm |
| Net weight | 7.8kg |
| 1 pc MIG270 |
| 1 pc MIG torch 15AK, 16mm² × 4m |
| 1 pc Electrode Holder 200A, Copper, 25mm² × 3m |
| 1 pc Earth Clamp 300A, Copper, 25mm² × 3m |
| 1 pc Wire Feeder SB-10J-250, 24m/min |
| 1 pc CO2Regulator 36V |
